200L自动摇臂式灌装机

本机是专门针对50-1500kg的等规格的液体桶包装而设计的智能化包装系统,下潜式液面上灌装。本机电气控制部分由电机、称重仪表等进行操作控制,使用调节方便,控制能力强。具有操作方便,生产效率高,适用范围广等特点。适用于各粘度级别的润滑油、基础油,以及中间体化工产品的原料、助剂的包装。产能稳定,操作简单,生产能力高,是大桶包装的理想设备。


本机利用称重的工作原理来实现灌装量的控制。物料自行流入(或通过泵供料输送)待装容器中去。


本机灌装部通过粗细双管路实现快灌装和慢灌装,且灌装流量可调。在灌装初始时双管路同时打开,待灌装至快灌装设定量后,粗管路关闭,细管路继续慢灌装,直至设定的整体灌装量。所有阀门、接口的密封件均采用聚四氟乙烯,使用温度-190~250℃,允许骤冷骤热,或冷热交替操作。



This machine is an intelligent packaging system specially designed for the packaging of liquid drums of 50-1500kg and the like, and it is filled with submerged liquid surface. The electrical control part of this machine is operated and controlled by motors, weighing instruments, etc. It is convenient to use and adjust, and has strong control capabilities. It has the characteristics of convenient operation, high production efficiency and wide application range. It is suitable for the packaging of lubricating oil, base oil, and intermediate chemical products of various viscosity grades and additives. With stable production capacity, simple operation and high production capacity, it is an ideal equipment for large barrel packaging.

This machine uses the working principle of weighing to control the filling volume. The material flows into the container to be packed by itself (or feed through the pump).

The filling part of this machine realizes fast filling and slow filling through thick and thin double pipelines, and the filling flow is adjustable. At the beginning of filling, both pipelines are opened at the same time. After filling to the set volume of fast filling, the thick pipeline is closed, and the thin pipeline continues to fill slowly until the set overall filling volume. All valves and interface seals are made of polytetrafluoroethylene, and the operating temperature is -190~250℃, and it is allowed to operate with sudden cooling and heating, or alternate operation of cooling and heating.


主要技术参数

Main technical parameters

防爆类型/Explosion-proof type

Exd II BT4

外形尺寸(长X宽X高)mm/Dimensions (length X width X height) mm

1500X1800X2800

灌装头数/Number of filling heads

1头/1head

灌装方式/Filling method

摇臂式/rocker type

生产能力/Production capacity

吨桶,约6-10桶/小时/IBC tank, about 6-10 drums/hour

灌装误差/Filling error

≤±0.1%

适用桶型/Applicable barrel type

吨桶/IBC tank

整机质量/Whole machine quality

约600kg/about 600kg

电源功率/Power supply power

AC380V/50Hz;3kW

气源压力/Air source pressure

0.6MPa
